MCO-1961: Integrate OSImageStream into MCP and sync logic #5476
Conversation
openshift-ci-robot
added
the
jira/valid-reference
|
@pablintino: This pull request references MCO-1961 which is a valid jira issue. Warning: The referenced jira issue has an invalid target version for the target branch this PR targets: expected the story to target the "4.21.0" version, but no target version was set. DetailsIn response to this:
Instructions for interacting with me using PR comments are available here. If you have questions or suggestions related to my behavior, please file an issue against the openshift-eng/jira-lifecycle-plugin repository. |
openshift-ci
bot
added
the
approved
pablintino
force-pushed
the
osimagestream-integration
branch
4 times, most recently
from
180934f to
eedbfd7
Compare
| // Early start the config informer because feature gate depends on it | ||
| ctrlctx.ConfigInformerFactory.Start(ctrlctx.Stop) | ||
| if fgErr := ctrlctx.FeatureGatesHandler.Connect(ctx); fgErr != nil { | ||
| klog.Error(fmt.Errorf("failed to connect to feature gates %w", fgErr)) | ||
| runCancel() | ||
| <-ctx.Done() | ||
| return | ||
| } |
There was a problem hiding this comment.
Moved earlier cause I need to check if the FeatureGateOSStreams is active at each controller instantiation.
| if fgErr := ctrlctx.FeatureGatesHandler.Connect(ctx); fgErr != nil { | ||
| klog.Fatal(fmt.Errorf("failed to connect to feature gates %w", fgErr)) | ||
| } | ||
|
|
There was a problem hiding this comment.
| mcfgv1.GroupVersion, apioperatorsv1alpha1.GroupVersion, | ||
| apicfgv1.GroupVersion, apicfgv1alpha1.GroupVersion, | ||
| corev1.SchemeGroupVersion, mcfgv1alpha1.GroupVersion, | ||
| imagev1.SchemeGroupVersion) |
There was a problem hiding this comment.
Needed to be able to read ImageStreams in https://github.com/openshift/machine-config-operator/pull/5476/files#diff-ee4889f36bd8b3bb13f51dd15721cbc3f0eae1cf4d6bb8635dec6de843e78c4dR184-R194
| case *imagev1.ImageStream: | ||
| for _, tag := range obj.Spec.Tags { | ||
| if tag.Name == "machine-config-operator" { | ||
| if imageStream != nil { | ||
| klog.Infof("multiple ImageStream found. Previous ImageStream %s replaced by %s", imageStream.Name, obj.Name) | ||
| } | ||
| imageStream = obj | ||
|
|
||
| } | ||
| } | ||
| // It's an ImageStream that doesn't look like the Release one (doesn't have our tag) |
There was a problem hiding this comment.
Try to read the Payload ImageStream the installer copies into our manifests dir. The content is used by the OSImageStream logic to fetch the CoreOS images, get the labels and group the images by stream label.
| iconfigs, err := template.RunBootstrap(b.templatesDir, cconfig, psraw, apiServer) | ||
| var osImageStream *mcfgv1alpha1.OSImageStream | ||
| // Enable OSImageStreams if the FeatureGate is active and the deployment is not OKD | ||
| if osimagestream.IsFeatureEnabled(fgHandler) { |
There was a problem hiding this comment.
If the feature is enabled we collect the streams and the bootstrap-time OSImageStream CR is created and passed to all the bootstrapping logic in each controller to properly generate the MCs pointing to the default stream and to make the CC urls point to it.
If the feature is not enabled nil is passed everywhere and the regular logic we use to have that uses the CC image urls is used instead.
| // GetBaseImageContainer returns the default bootable host base image. | ||
| func GetBaseImageContainer(cconfigspec *mcfgv1.ControllerConfigSpec, imageStream *v1alpha1.OSImageStreamSet) string { | ||
| if imageStream == nil { | ||
| return cconfigspec.BaseOSContainerImage | ||
| } | ||
| return string(imageStream.OSImage) | ||
| } | ||
|
|
||
| // GetBaseExtensionsImageContainer returns the default bootable host base image. | ||
| func GetBaseExtensionsImageContainer(cconfigspec *mcfgv1.ControllerConfigSpec, imageStream *v1alpha1.OSImageStreamSet) string { | ||
| if imageStream == nil { | ||
| return cconfigspec.BaseOSExtensionsContainerImage | ||
| } | ||
| return string(imageStream.OSExtensionsImage) |
There was a problem hiding this comment.
If an OSImageStream is given it takes precedence to the regular "cluster-wide image urls"
| imgRegistryUsrData := []mcfgv1.ImageRegistryBundle{} | ||
| if cfg.Spec.AdditionalTrustedCA.Name != "" { | ||
| cm, err := optr.ocCmLister.ConfigMaps(ctrlcommon.OpenshiftConfigNamespace).Get(cfg.Spec.AdditionalTrustedCA.Name) | ||
| if err != nil { | ||
| klog.Warningf("could not find configmap specified in image.config.openshift.io/cluster with the name %s", cfg.Spec.AdditionalTrustedCA.Name) | ||
| } else { | ||
| newKeys := sets.StringKeySet(cm.Data).List() | ||
| newBinaryKeys := sets.StringKeySet(cm.BinaryData).List() | ||
| for _, key := range newKeys { | ||
| raw, err := base64.StdEncoding.DecodeString(cm.Data[key]) | ||
| if err != nil { | ||
| imgRegistryUsrData = append(imgRegistryUsrData, mcfgv1.ImageRegistryBundle{ | ||
| File: key, | ||
| Data: []byte(cm.Data[key]), | ||
| }) | ||
| } else { | ||
| imgRegistryUsrData = append(imgRegistryUsrData, mcfgv1.ImageRegistryBundle{ | ||
| File: key, | ||
| Data: raw, | ||
| }) | ||
| } | ||
| } | ||
| for _, key := range newBinaryKeys { | ||
| imgRegistryUsrData = append(imgRegistryUsrData, mcfgv1.ImageRegistryBundle{ | ||
| File: key, | ||
| Data: cm.BinaryData[key], | ||
| }) | ||
| } | ||
| } | ||
| } | ||
|
|
||
| imgRegistryData := []mcfgv1.ImageRegistryBundle{} | ||
| cm, err := optr.clusterCmLister.ConfigMaps("openshift-config-managed").Get("image-registry-ca") | ||
| if err == nil { | ||
| newKeys := sets.StringKeySet(cm.Data).List() | ||
| newBinaryKeys := sets.StringKeySet(cm.BinaryData).List() | ||
| for _, key := range newKeys { | ||
| raw, err := base64.StdEncoding.DecodeString(cm.Data[key]) | ||
| if err != nil { | ||
| imgRegistryData = append(imgRegistryData, mcfgv1.ImageRegistryBundle{ | ||
| File: key, | ||
| Data: []byte(cm.Data[key]), | ||
| }) | ||
| } else { | ||
| imgRegistryData = append(imgRegistryData, mcfgv1.ImageRegistryBundle{ | ||
| File: key, | ||
| Data: raw, | ||
| }) | ||
| } | ||
| } | ||
| for _, key := range newBinaryKeys { | ||
| imgRegistryData = append(imgRegistryData, mcfgv1.ImageRegistryBundle{ | ||
| File: key, | ||
| Data: cm.BinaryData[key], | ||
| }) | ||
| } | ||
| } |
There was a problem hiding this comment.
Logic extracted to a common function used now by the OSImageStream sync function too.
There was a problem hiding this comment.
So, why is this code removed? It has been moved from the controller to the operator. Why? Cause we need to have the OSImageCluster CR created ASAP. While having a dedicated controller for the CR may make sense it's really hard to do so. Why?
- Each piece of code that reads the instance should take into consideration that the CR is not yet created.
- The ControllerConfig will require an extra sync to rewrite the OSImages with the content of the default stream, and that may rollout a undesired update.
- Given the nature of the CR, that never changes there's no need to create a controller for it.
The content of this file is approximately the code used in https://github.com/openshift/machine-config-operator/pull/5476/files#diff-3e205577bec1a1d1711df8bfeff30e63f044b24cfbdc69bbd7d0052fdc881891R1296
|
@pablintino: This pull request references MCO-1961 which is a valid jira issue. Warning: The referenced jira issue has an invalid target version for the target branch this PR targets: expected the story to target the "4.21.0" version, but no target version was set. DetailsIn response to this:
Instructions for interacting with me using PR comments are available here. If you have questions or suggestions related to my behavior, please file an issue against the openshift-eng/jira-lifecycle-plugin repository. |
|
/hold |
openshift-ci
bot
added
the
do-not-merge/hold
openshift-merge-robot
added
the
needs-rebase
pablintino
force-pushed
the
osimagestream-integration
branch
from
d614675 to
fed2a19
Compare
openshift-merge-robot
removed
the
needs-rebase
pablintino
force-pushed
the
osimagestream-integration
branch
from
fed2a19 to
c26a561
Compare
pkg/operator/sync.go
Outdated
| return nil | ||
| } | ||
|
|
||
| func (optr *Operator) syncOSImageStream(_ *renderConfig, _ *configv1.ClusterOperator) error { |
There was a problem hiding this comment.
praise: Moving this into the operator seems like a great idea!
pkg/operator/sync.go
Outdated
| defer buildCancel() | ||
|
|
||
| imageStreamFactory := osimagestream.NewDefaultStreamSourceFactory(optr.mcoCmLister, &osimagestream.DefaultImagesInspectorFactory{}) | ||
| osImageStream, err := osimagestream.BuildOsImageStreamRuntime(buildCtx, clusterPullSecret, minimalCC, image, imageStreamFactory) |
There was a problem hiding this comment.
question: Every time this runs, will this function reach out to the image registry, pull down the image, extract the imagestream and load it?
I ask because doing this with the frequency that the operator sync loop runs feels unnecessary when the image pullspec and / or digest of the release payload image have not changed. If the underlying library that we use to get the ImageStream from the release payload image caches what it pulled, then this is moot since we'll have a cache hit in that case. If not, we may want to do a bit of caching here in the operator.
It could be as simple as storing the image pullspec on the operator struct and determining whether the pullspec has changed. If the pullspec hasn't changed, then the ImageStream contained within the pullspec also hasn't changed, which means we could skip the more expensive parts of the sync operation.
There was a problem hiding this comment.
That's the main point of https://github.com/openshift/machine-config-operator/pull/5476/changes#diff-3e205577bec1a1d1711df8bfeff30e63f044b24cfbdc69bbd7d0052fdc881891R1315-R1318
The idea is that this inspection logic only run at bootstrap time or when an update happens (the OSImageStream has the controller version as apart of an annotation, if it matches the current version we skip the whole function).
That said, given that you ask, this means the code is not too explicit about the run-once nature of the code and maybe I need to split this function in two, one that does the check if the refresh is required with a clear descriptive comment stating the purpose of this sync is to run once and another one with the inspection/build logic. WDYT?
There was a problem hiding this comment.
I think splitting it up is a great idea and would help clarify this run-once nature you mentioned 😄
There was a problem hiding this comment.
@cheesesashimi I've addressed this, let me know if it's fine for you now.
pkg/operator/sync.go
Outdated
| return err | ||
| } | ||
|
|
||
| oscontainer, osextensionscontainer, err := optr.getOsImageURLs(optr.namespace) |
There was a problem hiding this comment.
unrelated: It's a bit strange that we seem to pass the namespace through here, given that it is very specific CM that only exists in the MCO namespace.
There was a problem hiding this comment.
Agree, I thought the same but I didn't address it. I'll leave this comment unresolved as a reminder to address it.
|
Overall the changes make sense to me! Thanks for putting this together. I did have a question about how the defaulting behavior works. I see the When the MCP spec doesn't define a certain stream, I assume the default above is to be used. When the pool does complete updating to the default, do we want this to be represented on the pool's status? In the current implementation, spec will follow status(and spec is empty in the default case). |
| // `OSImageStream` reference in the MCP status to be consistent to what is defined in the | ||
| // MCP spec | ||
| if osimagestream.IsFeatureEnabled(ctrl.fgHandler) { | ||
| status.OSImageStream = pool.Spec.OSImageStream |
There was a problem hiding this comment.
I ran into an issue w/ status while testing this PR. When the pool is in transition between two streams(I tried both forwards and backwards b/w rhel9 <-> rhel10), the status field seems to lose its value. Once the pool has finished updating, it seems to reflect the spec value. Are we somehow setting this value to empty when the pool is applying a new stream across its nodes? I can see that this check is only triggered when all nodes are updated, but I would've expected the pool status to remain rhel9 until it has completely transitioned all nodes to rhel10.
There was a problem hiding this comment.
Hm, that does seem like an issue. 😕 I think ideally we want to persist the old image stream until the update is complete, consistent to what we see for the rendered MC version. It seems we may be hitting some corner case where the perfect storm of the conditions is being met, possibly:
- The image stream is unset from the MCP spec
- A new rendered MC has not yet been created, so the MCP is not in an "Updating" state yet
- We're hitting this conditional and the image stream is being removed because the pool thinks it's updated to something new
I'll have to think more about how to handle this corner case because at initial glance nothing is coming to mind.
There was a problem hiding this comment.
Thanks for helping figure this out, David! It seems that recreating the status here https://github.com/pablintino/machine-config-operator/blob/c684f2345859bbfe7ea615be2ef08cb06d703f16/pkg/controller/node/status.go#L214-L223 is erasing the image stream in the status. Adding the following in the non-updated condition (in the https://github.com/pablintino/machine-config-operator/blob/c684f2345859bbfe7ea615be2ef08cb06d703f16/pkg/controller/node/status.go#L272 else) should do the trick. Other solutions are definitely possible depending on your preference, but the idea is in the non-updated sync case, we need to explicitly keep the pool.Status.OSImageStream unchanged.
if osimagestream.IsFeatureEnabled(ctrl.fgHandler) {
status.OSImageStream = pool.Status.OSImageStream
}
pkg/controller/template/render.go
Outdated
| // because it will look like an override when it shouldn't be. So don't take this out until you've solved that. | ||
| // And inject the osimageurl here | ||
| mcfg.Spec.OSImageURL = ctrlcommon.GetDefaultBaseImageContainer(config.ControllerConfigSpec) | ||
| // TODO: @pablintino do we need to do the same with the extensions? |
There was a problem hiding this comment.
So the context is in the old old way we did this, was that we simply ignored any osImageURL fields for any MachineConfigs either rendered by default, or provided by the user, and only allowed the configmap one to get rendered into the final machineconfig (when we did MergeMachineConfigs)
When we allowed overriding this field in 4.12(?) to allow for custom images, we inadvertantly caused users to use old images if:
- they accidentally provided a user-machineconfig with a osImageURL in it
- the MCO at some point rendered a MachineConfig into any generated-by-controller MCs
We couldn't really do anything about 1 since it's the same UX for off cluster layering, but (I think, my memory is hazy) we had this in place to prevent 2 from causing any problems. Now I think about it, maybe we should have cleared the field entirely and not had a "base template machineconfig with OSImageURL in it" and just let the rendering logic apply the default one to the final rendered-MC. This would also have circumnavigated the issue with "rhel10 pools" since now there's an inheritance model. For instance, if I want to use a off-cluster layered OSImageURL for rhel9 but just the default OSImageURL for RHEL 10, what happens if I provide that MC?
Extensions image was never an issue because 1. we didn't have it in really old versions and 2. we never had any overrides for it or any base template MC rendering.
There was a problem hiding this comment.
Thanks for the context @yuqi-zhang . I've continued the conversation in Slack and I think we can continue in #5488 too.
| for _, tag := range obj.Spec.Tags { | ||
| if tag.Name == "machine-config-operator" { | ||
| if imageStream != nil { | ||
| klog.Infof("multiple ImageStream found. Previous ImageStream %s replaced by %s", imageStream.Name, obj.Name) |
There was a problem hiding this comment.
out of curiosity when would this be possible? I was under the impression each payload would only have one tagged with MCO?
There was a problem hiding this comment.
It's just a defensive measure, in theory, we are only copying the payload ImageStream. I added the check to be 100% we load the one we expected to load in case a change in the installer makes another IS to sneak in.
| // The template configs always match what's in controllerconfig because they get rendered from there, | ||
| // so the only way we get an override here is if the user adds something different | ||
| osImageURL := GetDefaultBaseImageContainer(&cconfig.Spec) | ||
| osImageURL := GetBaseImageContainer(&cconfig.Spec, imageStream) |
There was a problem hiding this comment.
On the same vein as the comment below, this code is fine for setting the default from the stream, but the override logic just assumes any override is for both pools, since both rhel9 and rhel10 are still "workers". Wouldn't that cause an issue if someone provides a worker osImageURL since both rhel9 and rhel10 would be using it?
Hmm, although looking at the must-gather, we do have that by default in 00-master and 00-worker, but it seems that testing this does work with RHEL 10, so maybe I'm misunderstanding that somewhere?
| templateDir, | ||
| controllerConfig, | ||
| role, | ||
| osimagestream.TryGetOSImageStreamFromPoolListByPoolName(osImageStream, mcpPools, pool.Name), |
There was a problem hiding this comment.
question: why does the non-base MC generation code (for example, the containerruntimeconfig here) need the osimagestream info?
There was a problem hiding this comment.
As per Slack conversation, yes, it's not needed and I've removed it :)
Thanks for the pointer.
pablintino
force-pushed
the
osimagestream-integration
branch
from
c26a561 to
c684f23
Compare
| @@ -1,15 +1,55 @@ | |||
| package osimagestream | |||
|
|
|||
| import ( | |||
There was a problem hiding this comment.
thought (non-blocking): I had a random thought yesterday about a radically different approach:
The crux of the problem is that there is an ImageStream file contained within the release payload image that we need to extract, inspect, and do something with. What if we didn't have to get the pull secrets, look up the release payload image, fetch it, extract the files, etc.? What if the Kubelet could do the heavy-lifting for us?
Assuming we could inject the release payload image pullspec into the MCO deployment object, we could do one of two things:
- Use an init container to copy the ImageStream to an emptyDir volume before the MCO starts.
- Use an Image Volume to mount the release payload image as a volume into the MCO container. This has the caveat that image volumes are not yet a stable / default feature.
In either case, the Kubelet handles the heavy-lifting of getting the release payload image and making its files available to the MCO. The MCO only needs to read the ImageStream file from disk and deserialize it. However, the difficulty with this approach lies in having the CVO inject the release payload pullspec into the MCO deployment object. The CVO can render templates, but it only does so during bootstrap. And even then, it appears to only do so for its own manifests (e.g., the /install and/or /bootstrap dirs). At runtime, the CVO appears to sync all of the manifests that are in the /release-manifests dir as-is.
(To be clear: This was just a random idea that I wanted to put someplace for posterity. I am not asking you to reconsider your approach or to change anything 😄)
There was a problem hiding this comment.
Good alternative mate, complicated, but good. Maybe we can include it in the alternatives section of the EP? WDYT? @dkhater-redhat
openshift-merge-robot
added
the
needs-rebase
pablintino
force-pushed
the
osimagestream-integration
branch
2 times, most recently
from
1ed69a8 to
ce9a0ca
Compare
pablintino
force-pushed
the
osimagestream-integration
branch
from
ce9a0ca to
d307302
Compare
pablintino
force-pushed
the
osimagestream-integration
branch
from
4143926 to
015f071
Compare
pablintino
changed the title
pablintino
force-pushed
the
osimagestream-integration
branch
3 times, most recently
from
1cfd581 to
9b45abc
Compare
|
We have tested dual-stream in IPI on AWS HA and SNO. machine-config-daemon binariesWe saw that there is one binary for rhel8, another one for rhel9, but we didn't see any binary for rhel10. Is it intended? Basic functionalityNo issues found in SNO and HA regarding the basic functionality. Enabling rhel9 and rhel10 and switching between them. The new right image is applied to the nodes. Pause is working as expected too. Scaling up nodesSame when scaling up new nodes. They join to the cluster using the right rhel image. Custom poolsNo issues found either. Dual-stream works as intended when we use custom pools. Day1 installationOur day1 installation resulted in master pool being degraded. These are the manifests that we used: This is the degraded message: The reason for the degradation was a mismatch between the bootstrap MC and the first cluster MC. We included the bootstrapconfigdiff in the must gather file that can be found in: https://issues.redhat.com/browse/MCO-1915?focusedId=28689793&page=com.atlassian.jira.plugin.system.issuetabpanels%3Acomment-tabpanel#comment-28689793 ExtensionsOur cluster was degraded when we enabled the rhel10 stream and we tried to install extension. This is the degraded message: Note as well that when we try to degrade the MCP it is not immediately degraded. It seems an issue similar to https://issues.redhat.com/browse/OCPBUGS-62984 We can see in the logs that after saying that we are going to degrade the node, what we do is A must-gather file with the cluster's information can be found in: https://issues.redhat.com/browse/MCO-1915?focusedId=28689793&page=com.atlassian.jira.plugin.system.issuetabpanels%3Acomment-tabpanel#comment-28689793 We hit what seems to be another issue, but we are not sure since it is kind of masked by the previous extensions degradation. This is the scenario: 1- Enable rhel9 What's the expected behaviour here? the extensions should be re-installed, right? since the packages change. The behaviour that we see now is that no extension is installed and the rebase command fails
Kernel typesIf we configure realtime kernel in rhel10 the pool is degraded. In rhel9 it is deployed without problems. Steps to reproduce this issue:
If what we do is
The degradation reported is different |
pablintino
force-pushed
the
osimagestream-integration
branch
from
9b45abc to
158e485
Compare
|
We hit a problem upgrading a cluster using rhel-10. The fix seems to be already pushed. We will test it again. Updated status: With the new commit, the upgrade was successful using worker and master rhel10 and infra rhel9. The issue was fixed. |
This commit completes the OSImageStream integration by updating MachineConfigPool status to track the active stream and implementing the sync logic in the MCO operator. Key changes: - Set MachineConfigPool status.osImageStream to match spec when the pool is fully updated and the OSStreams feature gate is enabled. This provides visibility into which OS image stream is actively running on each pool. - Implement OSImageStream sync logic in the operator to check if a build is required before performing expensive image inspection, and handle CR creation/updates. - Extract RenderedMachineConfigPrefix constant to controller/common for reuse across template and render controllers. Co-authored-by: Zack Zlotnik <[email protected]> Co-authored-by: Isabella Janssen <[email protected]>
pablintino
force-pushed
the
osimagestream-integration
branch
from
158e485 to
668ed84
Compare
|
/test e2e-gcp-op-2of2 |
|
[APPROVALNOTIFIER] This PR is APPROVED This pull-request has been approved by: isabella-janssen, pablintino The full list of commands accepted by this bot can be found here. The pull request process is described here DetailsNeeds approval from an approver in each of these files:
Approvers can indicate their approval by writing |
|
/verified by @sergiordlr |
openshift-ci-robot
added
the
verified
|
@pablintino: This PR has been marked as verified by DetailsIn response to this:
Instructions for interacting with me using PR comments are available here. If you have questions or suggestions related to my behavior, please file an issue against the openshift-eng/jira-lifecycle-plugin repository. |
|
/unhold |
openshift-ci
bot
removed
the
do-not-merge/hold
|
/test e2e-hypershift |
|
/test e2e-hypershift |
|
/override ci/prow/e2e-hypershift Shouldn't affect hypershift in its current form |
|
@yuqi-zhang: Overrode contexts on behalf of yuqi-zhang: ci/prow/e2e-hypershift DetailsIn response to this:
Instructions for interacting with me using PR comments are available here. If you have questions or suggestions related to my behavior, please file an issue against the kubernetes-sigs/prow repository. |
|
@pablintino: The following test failed, say
Full PR test history. Your PR dashboard. DetailsInstructions for interacting with me using PR comments are available here. If you have questions or suggestions related to my behavior, please file an issue against the kubernetes-sigs/prow repository. I understand the commands that are listed here. |
openshift-merge-bot
bot
merged commit bf7ba38
into
openshift:main
|
/woof |
DetailsIn response to this:
Instructions for interacting with me using PR comments are available here. If you have questions or suggestions related to my behavior, please file an issue against the kubernetes-sigs/prow repository. |
8 participants
- What I did
This change integrates the already existing OSImageStream logic into the MCO reconcile logic.
The change covers:
- How to verify it
TBD.
- Description for the changelog
Integrated OSImageStream logic into MCO reconcile flow, covering bootstrapping and runtime config, with error handling improvements for network stability and a refactored sync function.
